Model：JX-2GL
Brand：Shanghai Jingxin
Specifications ：Set
Introduction：JX soil ball mill is a special high-performance mechanical equipment for the preparation of small ultra-fine powders, which is innovatively improved and developed by our company.
Product Description:
JX Soil Ball Mill is a special high-performance mechanical equipment for the preparation of small ultra-fine powders, which is innovatively improved and developed by our company. A large number of user applications show that the soil ball mill has the characteristics of small size, light weight, easy operation and no pollution, and is very suitable for the use of various types of soil grinding in the laboratory. The advanced planetary structure of the soil machine increases the grinding efficiency by more than ten times; the four tanks are separately charged, so that different materials do not affect each other. Gear transmission ensures the consistency and repeatability of the experiment; fast rotation, high energy Large, high efficiency and fine particle size; four samples of different sizes and materials can be obtained simultaneously in one experiment;
Soil ball mill advantages:
1. Injection size: ≤10 mm, other materials ≤3mm, discharge particle size: <100nm, dry grinding or wet grinding;
2. The pressure can be set (by the scale), digital timing;
3. 7 kinds of grinding kits of different materials can be provided: stainless steel, agate, etc.
4. Real-time power display, crushing time setting, digital format, continuous operation from 1 to 99 minutes;
5. The grinding chamber is designed to be sealed and dustproof, with observation window;
6. High-power drive, with electronic monitoring device.
Technical parameter:
The main parameters
Parameter range
Brand name:
JXFSTPRP net letter
product name:
Soil Ball Mill
Model:
JX-2GL
Operation method:
LCD liquid crystal touch display
Injection size (varies in material):
≤10mm, other materials ≤3mm
Sample size:
<100nm
Processing volume:
50ml/can
Ball mill tank capacity:
4x100ml
Main disc speed:
35-435r/min
Ball mill rotation speed:
70-870r/min
Transmission ratio (planetary disc/ball mill):
1:2
Forward and reverse operation:
Yes
Continuous running time setting:
1-9999 min
Pause time setting:
1-999 min
Dangerous emergency stop:
Grinding Room Lighting Description:
LED blue light
Touch screen:
adaptation
Vector volume:
50ml -100ml
Ball Milling Media Material:
Stainless steel, agate, zirconia, corundum, nylon, teflon optional
Media Diameter:
3/5/10/15/20mm
Media Quality:
100-400g
Grinding method:
Dry grinding / Wet grinding
Low temperature cooling treatment:
Yes (additional)
Inert gas protection treatment:
Net weight:
29kg
Dimensions (length, width and height):
530*300*340mm
Standard:
JXFSTPRP Jingxin
Tank ball ratio:
Grinding jar
100ml
Effective volume
1-50ml
Ball size
Number of balls
5mm
300
10mm
30
15mm
15
20mm
8
Experimental case:
1. Description:
(1) Application field: environment;
(2) Materials/raw materials: soil, pebbles;
(3) Feed particle size: 1mm;
(4) Feeding amount: 500g;
(5) Material properties: brittle;
(6) Customer requirements: 50μm;
(7) Post-sequence analysis: particle size analysis.
2. Scheme:
(1) Equipment (instrument) selection: JX-2G, soil ball mill;
(2) Jar and ball configuration: agate jar with agate ball;
(3) Operating parameters: 500 r/min rotation, alternately running forward and reverse after 30 minutes;
(4) Grinding time: 1 hour;
(5) Result (recommended): JX-2G can be used to grind the soil;
(6) Grinding result: 100%＜50μm.
